Model Name | DR750X-2CH TRUCK |
Channel | 2CH |
Highlights | Full HD (Front + External Waterproof IR Cam), Cloud, Wi-Fi, GPS, Dual Sony Sensors, External LTE Module (Optional) |
Product Dimensions | Front: W 118.5 mm (4.67″) x H 36 mm (1.42″) / 105g (3.70 oz) Rear: W 70.0 mm (2.76″) x H 44.4 mm (1.75″) / 180 g (6.35 oz) |
Rear Camera Connection | Waterproof coaxial cable |
Memory Support | microSD card up to 256GB |
Recording Modes | – Normal, – Event (Impact Detection / Speed Limit / Manual), – Parking Mode (Impact+Region-based Motion Detection, Timelapse+Events) |
Parking Mode | YES (with 3-wire hardwiring cable – included) |
Parking Mode Event Voice Notifications | YES |
Imaging Sensor | Front: Sony STARVIS™ CMOS Sensor (Approx. 2.1MP) Rear: CMOS Sensor (Approx. 2.1MP) |
Viewing Angle | Front: Diagonal 139°, Horizontal 116°, Vertical 61° Rear: Diagonal 120°, Horizontal 100°, Vertical 60° |
Resolution Frame Rate | Front / Rear Full HD @60fps – Full HD @30fps * Frame rate may vary during Wi-Fi streaming |
Video Codec | H.264 (AVC) |
Image Quality and Bitrate Front/Rear | Highest (Extreme): 25+10 Mbps Highest: 12+10 Mbps High: 10+8 Mbps Normal: 8+6 Mbps |
Format Free | YES (Adaptive) |
Event File Overwrite Protection | YES (up to 50) |
SD Card Failure Alert | YES |
Scheduled Reboot | YES |
Video File Extension | MP4 |
Wi-Fi | Built-in (802.11 b.g.n) |
Cloud Compatible | YES |
GPS | Built-in (Dual Band : GPS, GLONASS) |
Microphone | Built-in |
Speaker | Built-in |
Impact Sensor | 3-Axis Acceleration Sensor |
LED Indicators | Front: Recording LED, GPS LED, LTE/Wi-Fi LED, Front Security LED, Proximity Sensing indicator LED Rear: Rear Security LED |
Rear Camera IR Illumination | 940 nm, 6 Infrared (IR) Lights |
Button | Button: Wi-Fi ON/OFF (Tap) Proximity sensor: Mic ON/OFF / Trigger Manual Recording / OFF (configurable) |
Operation Temperature | -20 °C − 85 °C (-4 °F − 185 °F) |
Storage Temperature | -20 °C − 90 °C (-4 °F − 194 °F ) |
High Temp Cut Off | Approx. 85 °C (185 °F) |
Backup Battery | Built-in supercapacitor |
Input Power | DC 12V-24V (DC Plug (Ø3.5 x Ø1.35)) to Wires (Black: GND / Yellow: B+ / Red: ACC) |
Power Consumption Hour | Normal Mode (WiFi On / GPS On / 2CH) : 395mA / hour Normal Mode (WiFi Off / GPS On / 2CH) : 360mA / hour Parking Mode (WiFi On / GPS Off / 2CH) : 340mA / hour Parking Mode (WiFi Off / GPS Off / 2CH) : 305mA / hour * Approx. 60mA increase in current when IR LEDs are ON. * Actual power consumption may vary depending on use conditions and environment. |
Certifications | Front: FCC, CE, RoHS, Telec, WEEE, IC Rear: FCC, CE, RoHS, WEEE |
software | BlackVue Viewer * Windows 7 or higher and Mac Yosemite OS X (10.10) or higher |
Application | BlackVue Application (Android 5.0 or higher, iOS 9.0 or higher) |
Others | Adaptive Format-Free File Management System |
LTE | External (Optional) |
