Free PC Sound Tuning Software
iOS, Android, and Desktop PC Tuning Software
Bluetooth Audio Streaming with Included External Module
Remote Controller Included
Digital Time Correction
2019 CES Innovation Awards Winner
Specifications
RMS: 25W x 4 + 165W
Peak power: 50W x 4 + 240W
4 RCA/Speaker Level Inputs
10-Band Parametric EQ
Signal-to-noise ratio: ≥80dB
Bass boost: -12dB~+12dB
Frequency response: 20Hz~20KHz
Input impedance: Low-level input: 20KΩ
Input impedance: High-level input: 100Ω
Phase selection: 0°/180°
Remote ON: DC high-level /REM input activation
Storage temperature: -40~85°C
Power source: DC 14.4V (9V~16V) negative ground
Activate REM input: High-level activation (H1+/H3+)
Activate REM output: +12V activation output (0.5A)
Stand-by current: 750mA
Signal Type: 4-channel high-level
Signal Type: 4-channel low-level
4-channel amplifier output (4Ω 50W x 4)
Master volume: 0~35
Subwoofer volume: 0~15
PreSets: 15 PreSets Selectable
Dimensions (mm): 350 L x 245 W x 80 H
Weight: 5.35kg
PWD-X5 software download files:Mobile App download
Software for PC download
Click here for further instructions.
