Features
- 10.1” WSVGA Screen LED Display (1.84 million pixels)
- Built-in Durable Automotive Frade DVD/CD Player
- Supported Disk Media: DVD+R/RW/DVD-R/RW/CD-RW
- Supported USB/HDMI Media: AVI/MPEG/MP4/MOV/FLV/RMVB/JPEG (Up to 720 x 480 Resolution) Playback
- Auto DVD Play
- MP3/WMA/AAC Playback
- Dual HDMI Inputs (PKG-RSE3HDMI only)
- Dual USB Inputs (PKG-RSE3HDMI only)
- 1 Aux Input/ 1 Aux Output
- Built-in FM Modulator and IR Transmitter
- 2 Pairs of Wireless IR Headphones (SHS-N106) Included
- Multi Function Remote Control Included
- 3 Colour Options Included (Black, Grey, Beige)
- Includes Cable/Harness and Installation Kit with Trim Ring
Specifications
DISPLAY SCREEN
- Size: 10.1″
- Width 221mm: (8.70”)
- Height 132mm: (5.20”)
- Aspect Ratio: 16:9
- Type Transparent type: TN 2.35A (MAX) 1.60A (TYP) 140mA (Stand by)
- Depth: 290 mm (11.42”)
- Height (LCD Panel Closed): 45 mm (1.7”)
- Weight: 2.270 Kg (5.0lbs)
- System Number of Elements: Liquid Crystal Display TFT-LCD, Active Matrix 1024(W) x 600(H) x 3 1.84M Pixels (WSVGA)
- Effective Number of Elements: 99.9% or more
- Back Light: LED
GENERAL
- Operating Voltage: 10 – 16 V DC (Typical: 12V)
- Power Consumption:
- Video Input: 1.0V p-p 75ohm
- Audio Input: 2.0V RMS (max)
- IR Transmitter: CH A: 2.3MHz / 2.8MHz CH B: 3.2 MHz / 3.8MHz
- FM Modulator: 88.1MHz – 92.1MHz PLL Frequency Synthesizer
- Operating Temperature: -4 ̊F to +158 ̊F (-20 ̊C to + 70 ̊C)
MONITOR
- Width: 290 mm (11.42”)
- Height (LCD Panel Open): 204.2 mm (8.04″)
